GEPRC GEP LC75 V3 Long Range Frame Kit

SPECIFICATIONS:

• Model: GEP-LC75 V3
• Size: 7.5 inch
• Wheelbase: 342mm
• Top plate: 2.5mm
• Bottom plate: 3.0mm
• Arm plate: 6.0mm
• FC mounting hole: 30.5mm*30.5mm
• VTX mounting hole:20mm*20mm / 25.5mm*25.5mm
• Motor mounting hole: 16mm*16mm / 19mm*19mm
• Camera mounting hole: 19mm / 20mm
• Recommended propeller size: 7-7.5inch
• Weight: 266g

PACKAGE INCLUDES:

Carbon plate list:

1 x GEP-LC75 V3 top plate
1 x GEP-LC75 V3 bottom plate
4 x GEP-LC75 V3 arms plate
1 x GEP-LC75 V3 front splint plate
1 x GEP-LC75 V3 front splint plate

Accessories:

1 x Header printed parts
1 x Tail printed parts
1 x GP camera base
4 x Motor damping pad
1 x Nylon front side plate (Pair)
1 x Nylon Rear side plate (Pair)(O3 version)
1 x Nylon Rear side plate (Pair) (universal version)
1 x XT60EW-M plug
2 x Rubber elastic anti-slip straps 20*250mm
4 x Motor wire hub 60mm*10mm

Screw kits:

4 x M3*5*30 mesh aluminum columns
4 x M3*5*21.5 mesh aluminum columns
10 x M3 Countersunk head Gaskets – wine red
6 x M3 pressed Rivet nuts
8 x M3*8 shock absorbing balls
10 x countersunk hexagon socket screws M3*8
4 x countersunk hexagon socket screws M3*12
4 x Hexagon socket screws with semicircular head M3*8
16 x Hexagon socket screws with semi-round head M3*11
8 x semi-round head hexagon socket screws M3*16
4 x countersunk hexagon socket screws M3*16
4 x Hexagon socket screws with semi-round head M3*25
6 x M3 aluminum alloy hexagonal lock nuts
2 x Hexagon socket screws with half round head M2*6
4 x round head hex socket screws with pad M2*4
4 x O3 Air Unit Silicone gasket
6 x Cup-head hex socket screws M1.6*12
4 x Hexagon socket screws with half round head M2*23
4 x Self-tightening nuts M2
4 x Nylon columns M2*5
4 x Hexagon socket screws with half round head _ Black Nickel plated M2*7
4 x M2 Nylon nuts
8 x Hexagon socket screws with semicircular head M3*6
4 x black mesh M3*13 aluminum columns
