The iFlight Defender 25 Motor is designed for an ultralight build. This 1404 4150KV motor is light and durable and allows pilots to stay in the Sub250 category.
Features:
Works well with the iFlight Defender 25
Ultralight Motor
CW/CCW
Includes:
1x iFlight Defender 25 1404 Motor – 4150KV (CW/CCW)
4x M2x5 Screws
Specifications
Mounting Holes: 3 x 9 x 9 /2mm (3 mounting holes)
Shaft Protruding Length: 1.8mm/0.2mm
Winding: Single Strand copper winding
Rotor Specifications: Segmented bell
Weight (including wire): 8g/0.5g
Interphase Resistance: 0.188Ω
Bearing Specification: 5x2x2.5
Model: Defender 25 Motor
Dimension: 17.7×12.5mm
Shaft Diameter: 1.5mm
Magnet: N52H Curved
Peak Current: 12.03A
Configuration: 9N12P
Lead: 65mm/26AWG
Bearing Type: NMB
Max Watt: 200.8W
Input Volts: 4S
Rotation: CW/CCW
KV: 4150KV
Rotation
CW, CCW
