IFLIGHT Nazgul Evoque F6D DeadCat (DC) V2 Frame Kit

Original price was: ₹12,999.00.Current price is: ₹9,999.00.

Specifications :

  • Frame wheelbase : 255mm (Squashed X) / 262 mm (DeadCat)
  • Frame Dimension : L196*W164*H36 mm (Squashed X) / L209*W162*H36 mm (DeadCat)
  • Arm Thickness : 6mm
  • Frame Body Dimension : 36mm
  • Bottom Plate Thickness : 3mm
  • Top Plate Thickness : 2mm
  • Upper Plate Thickness : 3mm
  • Camera Plate Thickness : 3mm
  • Motor Mounting : 16x16mm
  • VTX Mounting : 25.5*25.5 φ1.6mm
  • Weight : 150grams (Included no TPU Parts)
SKU: KRCsURCV8PC8 Categories: , ,
Guaranteed Safe Checkout

Features:

  • V1 to V2 was upgraded for the DJI O3 HD Air Unit Digital Transmission
  • Specially Designed Heatsink for DJI O3 Air Unit
  • New Camera Mount for a wider camera FOV with TPU damping inserts
  • New Side Panels to perfectly fit the O3 Air Unit in the back
  • New Dual 5.8G VTX Antenna TPU mount
  • Latest Nazgul Frame Upgrades for Maximum Protection

Optional Parts to select (not included in frame kit):

New Anti Spark Filter to prevent rapid voltage and current spikes plugging in a battery

Single DJI VTX Antenna TPU to install the original DJI O3 set included antenna.

Package included :

  • 1 x Evoque F6 V2 Frame Kit
  • 1 x O3 Air Unit Heatsink
  • 2 x O3 IPEX to RP-SMA Antenna Pigtails
  • 1 x O3 Dual Antenna
  • 1 x GoPro TPU Base Mount
  • 2 x Anti-slip Battery Pad
  • 4 x TPU Armguard
  • 1 x Front Bumper TPU
  • 1 x Rear Bumper TPU
  • 2 x Anti-slip Battery Pad
  • 2 x Battery Strap (20*250mm)
  • 1 x Battery Strap(20*250mm)
  • 1 x Screw Bag
