IFLIGHT Nazgul Evoque F6D DeadCat (DC) V2 Frame Kit
Original price was: ₹12,999.00.₹9,999.00Current price is: ₹9,999.00.
Specifications :
- Frame wheelbase : 255mm (Squashed X) / 262 mm (DeadCat)
- Frame Dimension : L196*W164*H36 mm (Squashed X) / L209*W162*H36 mm (DeadCat)
- Arm Thickness : 6mm
- Frame Body Dimension : 36mm
- Bottom Plate Thickness : 3mm
- Top Plate Thickness : 2mm
- Upper Plate Thickness : 3mm
- Camera Plate Thickness : 3mm
- Motor Mounting : 16x16mm
- VTX Mounting : 25.5*25.5 φ1.6mm
- Weight : 150grams (Included no TPU Parts)
Features:
- V1 to V2 was upgraded for the DJI O3 HD Air Unit Digital Transmission
- Specially Designed Heatsink for DJI O3 Air Unit
- New Camera Mount for a wider camera FOV with TPU damping inserts
- New Side Panels to perfectly fit the O3 Air Unit in the back
- New Dual 5.8G VTX Antenna TPU mount
- Latest Nazgul Frame Upgrades for Maximum Protection
Optional Parts to select (not included in frame kit):
New Anti Spark Filter to prevent rapid voltage and current spikes plugging in a battery
Single DJI VTX Antenna TPU to install the original DJI O3 set included antenna.
Package included :
- 1 x Evoque F6 V2 Frame Kit
- 1 x O3 Air Unit Heatsink
- 2 x O3 IPEX to RP-SMA Antenna Pigtails
- 1 x O3 Dual Antenna
- 1 x GoPro TPU Base Mount
- 2 x Anti-slip Battery Pad
- 4 x TPU Armguard
- 1 x Front Bumper TPU
- 1 x Rear Bumper TPU
- 2 x Anti-slip Battery Pad
- 2 x Battery Strap (20*250mm)
- 1 x Battery Strap(20*250mm)
- 1 x Screw Bag
